GDM-906X Series User Manual
124
User Mode – Switch Mode (Relay)
Overview
It is the mode driving Relay to control external circuit with up
to 4 pins available for use simultaneously. Refer to the
following introductions along with diagrams for more details.
Please see the digital I/O commands on page 272 for full
usage details.
Related
Commands
DIG:INT:MODE IO (switch to IO mode)
DIG:INT:DATA:SET 1,0,1,0
=> OUT1(Pin5) : RELAY OFF
OUT2(Pin6) : RELAY ON
OUT3(Pin7) : RELAY OFF
OUT4(Pin8) : RELAY ON
Pin
Assignment
Pin No
User Mode
Description
1
VCC Out
Option(Vcc:+5V)
2
Flyback Diode
Use (connect to Pin1 or
Ext Vcc)
3
Digital Ground
GND
5
OUT1
Use
6
OUT2
Use
7
OUT3
Use
8
OUT4
Use
