GW Instek GDM-906 Series - Insert GPIB Card (Optional)

REMOTE CONTROL
213
Insert GPIB Card (Optional)
Power Off
Turn the Power Off and take out the power cord.
Open the
GDM-906X optional
communication
port
Take off the two screws on the slot corners to remove
the optional communication port cover. Keep the screws
for later reuse.
Insert the GPIB
card
Insert the GPIB card into the slot. Close the cover by
tightening the screws.
Power On
Connect the power cord and turn On the power.
