GW Instek GDM-906 Series User Manual

GDM-9061 Section
347
AC Characteristics
[1]
True RMS AC Voltage
[2] [3] [4]
Range
[2]
Frequency
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
100 mV
3 Hz - 5 Hz
1.00 + 0.03
1.00 + 0.04
1.00 + 0.04
0.100 + 0.004
5 Hz - 10 Hz
0.35 + 0.03
0.35 + 0.04
0.35 + 0.04
0.035 + 0.004
10 Hz - 20 kHz
0.04 + 0.03
0.05 + 0.04
0.06 + 0.04
0.005 + 0.003
20 kHz - 50 kHz
0.10 + 0.05
0.11 + 0.05
0.12 + 0.05
0.011 + 0.005
50 kHz - 100 kHz
0.55 + 0.08
0.60 + 0.08
0.60 + 0.08
0.060 + 0.008
100 kHz - 300 kHz
4.00 + 0.50
4.00 + 0.50
4.00 + 0.50
0.200 + 0.020
1 V ~ 750 V
3 Hz - 5 Hz
1.00 + 0.02
1.00 + 0.03
1.00 + 0.03
0.100 + 0.004
5 Hz - 10 Hz
0.35 + 0.02
0.35 + 0.03
0.35 + 0.03
0.035 + 0.004
10 Hz - 20 kHz
0.04 + 0.02
0.05 + 0.03
0.06 + 0.03
0.005 + 0.003
20 kHz - 50 kHz
0.10 + 0.04
0.11 + 0.05
0.12 + 0.05
0.011 + 0.005
50 kHz - 100 kHz
0.55 + 0.08
0.60 + 0.08
0.60 + 0.08
0.060 + 0.008
100 kHz - 300 kHz
4.00 + 0.50
4.00 + 0.50
4.00 + 0.50
0.200 + 0.020
Accuracy Specifications: ± ( % of reading + % of range )
True RMS AC Current
[2] [4] [5]
Range
[2]
Burden
Voltage
Frequency
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
100 μA/
10 mA
< 0.011 V,
< 0.04 V
3 Hz – 5 Hz
1.00 + 0.04
1.00 + 0.04
1.00 + 0.04
0.100 + 0.006
5 Hz – 10 Hz
0.35 + 0.04
0.35 + 0.04
0.35 + 0.04
0.035 + 0.006
10 Hz – 5 kHz
0.10 + 0.04
0.10 + 0.04
0.10 + 0.04
0.015 + 0.006
5 kHz – 10 kHz
0.18 + 0.04
0.18 + 0.04
0.18 + 0.04
0.030 + 0.006
1 mA/
100 mA
< 0.11 V,
< 0.4 V
3 Hz – 5 Hz
1.00 + 0.04
1.00 + 0.04
1.00 + 0.04
0.100 + 0.006
5 Hz – 10 Hz
0.30 + 0.04
0.30 + 0.04
0.30 + 0.04
0.035 + 0.006
10 Hz – 5 kHz
0.10 + 0.04
0.10 + 0.04
0.10 + 0.04
0.015 + 0.006
5 kHz – 10 kHz
0.15 + 0.04
0.15 + 0.04
0.15 + 0.04
0.030 + 0.006
1 A
< 0.7 V
3 Hz – 5 Hz
1.00 + 0.04
1.00 + 0.04
1.00 + 0.04
0.100 + 0.006
5 Hz – 10 Hz
0.30 + 0.04
0.30 + 0.04
0.30 + 0.04
0.035 + 0.006
10 Hz – 5 kHz
0.10 + 0.04
0.10 + 0.04
0.10 + 0.04
0.015 + 0.006
5 kHz – 10 kHz
0.15 + 0.04
0.15 + 0.04
0.15 + 0.04
0.030 + 0.006
3 A
< 2.0 V
3 Hz – 5 Hz
1.00 + 0.04
1.00 + 0.04
1.00 + 0.04
0.100 + 0.006
5 Hz – 10 Hz
0.35 + 0.04
0.35 + 0.04
0.35 + 0.04
0.035 + 0.006
10 Hz – 5 kHz
0.23 + 0.04
0.23 + 0.04
0.23 + 0.04
0.015 + 0.006
5 kHz – 10 kHz
0.23 + 0.04
0.23 + 0.04
0.23 + 0.04
0.030 + 0.006
