GW Instek GDM-906 Series User Manual

GDM-906X Series User Manual
348
10 A
[6]
< 0.5 V
3 Hz – 5 Hz
1.10 + 0.04
1.10 + 0.04
1.10 + 0.04
0.100 + 0.006
5 Hz – 10 Hz
0.35 + 0.04
0.35 + 0.04
0.35 + 0.04
0.035 + 0.006
10 Hz – 5 kHz
0.15 + 0.04
0.15 + 0.04
0.15 + 0.04
0.015 + 0.006
5 kHz – 10 kHz
0.35 + 0.04
0.35 + 0.04
0.35 + 0.04
0.030 + 0.006
Accuracy Specifications: ± ( % of reading + % of range )
Additional Crest Factor Errors (non-sine wave)
Crest Factor
Error (% of reading)
1-2
0.05%
2-3
0.15%
3-4
0.30%
4-5
0.40%
Additional Low Frequency Errors (% of reading)
Frequency
Speed
1/s (>3 Hz)
5/s (>20 Hz)
20/s (>200 Hz)
10 Hz~20 Hz
0
0.74
-
20 Hz~40 Hz
0
0.22
-
40 Hz~100 Hz
0
0.06
0.73
100 Hz~200 Hz
0
0.01
0.22
200 Hz~1 k Hz
0
0
0.18
>1 k Hz
0
0
0
