GDM-906X Series User Manual
214
Configure GPIB Interface
GPIB Configuration
Connector
24 Pin female GPIB port
Address
0-30(default 15)
Step
1. Press the Menu key, and then
the Page Down key repeatedly
until the Interface
configuration menu appears.
2. Press the F5 (Enter) key or
Knob key followed by scrolling
Knob key or pressing +/- keys
to land on the GPIB option.
Note: The GPIB menu will be
selectable only when the GPIB
card is installed.
