GW Instek GDM-906 Series User Manual

SCREENSHOT & LOG
175
Save Reading
Background
Configure the mode of data log saving.
Step
1. Press the Shift key followed by the
LOG/LOG# key and the
following menu appears.
2. Press the F1 (Log Mode) key
followed by clicking the F2
(SaveRead) key to enable the Save
and Read mode for data log.
3. Press the F2 (FileName) key to
enter the Log FileName Mode
menu. Further press the F1
(Default) key to let system saves
screenshot by auto name in serial
number or press the F2 (Manual)
key to determine file name by user.
Number
Range
For Count Source
 The auto name in serial number ranges
from DATAC000 to DATAC999.
For Recent Source
 The auto name in serial number ranges
from DATAR000 to DATAR999.
Number
Zero
Repluging the USB disk will zero the serial
number to the initial.
Note
When the serial number reaches the
maximum, e.g., DATAC999, the save action
will be Not available.
