GDM-906X Series User Manual
24
Set Up
Horizontal/Tilt/Vertical Applications
Pull out the handle sideways and rotate it clockwise for the applications below.
Horizontal
Tilt
Place the unit horizontally.
Rotate the handle for tilt stand.
Vertical
Place the handle vertically for hand carry.
