GDM-9060 Section
DC Characteristics
[1]
DC Voltage
Range
[2]
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
100.0000 mV
0.0040 + 0.0060
0.0070 + 0.0065
0.0090 + 0.0065
0.0005 + 0.0005
1.000000 V
0.0030 + 0.0009
0.0060 + 0.0010
0.0080 + 0.0010
0.0005 + 0.0001
10.00000 V
0.0025 + 0.0004
0.0050 + 0.0005
0.0075 + 0.0005
0.0005 + 0.0001
100.0000 V
0.0030 + 0.0006
0.0065 + 0.0006
0.0085 + 0.0006
0.0005 + 0.0001
1000.000 V
0.0030 + 0.0006
0.0065 + 0.0010
0.0085 + 0.0010
0.0005 + 0.0001
Accuracy Specifications: ± ( % of reading + % of range )
Resistance
[3]
Range
[2]
Test
Current
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
100.0000 Ω
1 mA
0.004 + 0.0060
0.011 + 0.007
0.014 + 0.007
0.0006 + 0.0005
1.000000 kΩ
1 mA
0.003 + 0.0008
0.011 + 0.001
0.014 + 0.001
0.0006 + 0.0001
10.00000 kΩ
100 μA
0.003 + 0.0005
0.011 + 0.001
0.014 + 0.001
0.0006 + 0.0001
100.0000 kΩ
10 μA
0.003 + 0.0005
0.011 + 0.001
0.014 + 0.001
0.0006 + 0.0001
1.000000 MΩ
5 μA
0.003 + 0.0010
0.011 + 0.001
0.014 + 0.001
0.0010 + 0.0002
10.00000 MΩ
500 nA
0.015 + 0.0010
0.020 + 0.001
0.040 + 0.001
0.0030 + 0.0004
100.0000 MΩ
500 nA//
10 MΩ
0.300 + 0.0100
0.800 + 0.010
0.800 + 0.010
0.1500 + 0.0002
Accuracy Specifications: ± ( % of reading + % of range )
DC Current
Range
[2]
Burden
Voltage
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
100.0000 μA
<0.011 V
0.010 + 0.020
0.040 + 0.025
0.050 + 0.025
0.0020 + 0.0030
1.000000 mA
<0.11 V
0.007 + 0.006
0.030 + 0.006
0.050 + 0.006
0.0020 + 0.0005
10.00000 mA
<0.04 V
0.007 + 0.020
0.030 + 0.020
0.050 + 0.020
0.0020 + 0.0020
100.0000 mA
<0.4 V
0.010 + 0.004
0.030 + 0.005
0.050 + 0.005
0.0020 + 0.0005
1.000000 A
<0.7 V
0.050 + 0.006
0.080 + 0.010
0.100 + 0.010
0.0050 + 0.0010
3.000000 A
<2.0 V
0.180 + 0.020
0.200 + 0.020
0.200 + 0.020
0.0050 + 0.0020
Accuracy Specifications: ± ( % of reading + % of range )
Continuity
Range
[2]
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
1 kΩ
0.003 + 0.030
0.011 + 0.030
0.014 + 0.030
0.001 + 0.002
Accuracy Specifications: ± ( % of reading + % of range )
