GW Instek GDM-906 Series User Manual

GDM-9060 Section
363
T
-200 to +400 °C
0.002 °C
0.3 °C
0.04 °C / °C
K
-200 to +1372 ˚C
0.002 °C
0.3 °C
0.04 °C / °C
N
-200 to +1300 ˚C
0.003 °C
0.4 °C
0.05 °C / °C
R
-50 to +1768 ˚C
0.01 °C
1 °C
0.14 °C / °C
S
-50 to +1768 ˚C
0.01 °C
1 °C
0.14 °C / °C
B
+350 to +1820 ˚C
0.01 °C
1 °C
0.14 °C / °C
*Relative to simulated junction
Thermistor: (2.2 kΩ, 5 kΩ, 10 kΩ or User Type)
Range
Resolution
90 Day / 1Year
(23 °C ±5 °C)
Temperature
Coefficient / °C
–80 ° to 150 °C
0.01 °C
0.01 °C
0.003 °C/ °C
Reading Rate
(Readings/sec)
TCO/RTD/
Thermistor
Speed
Digits
5/s
6 ½
20/s
5 ½
60/s
4 ½
[1]. The actual measurement range and test lead error will be constrained
by the adopted test lead. The test lead accuracy adder covers all errors
of measurements and ITS-90 temerature change.
Capacitance
[1]
Range
24 Hour
TCAL ± 1 ˚C
90 Day
TCAL ± 5 ˚C
1 Year
TCAL ± 5 ˚C
Temperature
Coefficient/˚C
1.000 nF
2.00 + 2.00
2.00 + 2.00
2.00 + 2.00
0.05 + 0.05
10.00 nF
2.00 + 1.00
2.00 + 1.00
2.00 + 1.00
0.05 + 0.01
100.0 nF
2.00 + 0.40
2.00 + 0.40
2.00 + 0.40
0.05 + 0.01
1.000 μF
2.00 + 0.40
2.00 + 0.40
2.00 + 0.40
0.05 + 0.01
10.00 μF
2.00 + 0.40
2.00 + 0.40
2.00 + 0.40
0.05 + 0.01
100.0 μF
2.00 + 0.40
2.00 + 0.40
2.00 + 0.40
0.05 + 0.01
Accuracy Specifications: ± ( % of reading + % of range )
[1]. Specifications are for film Capacitance inputs that are greater than 10% range.
