GDM-906X Series User Manual
38
Connect the test
lead and measure
Connect the test lead between the
3A terminal and the Input LO
terminal or DC/AC 10A terminal
and the Input LO terminal,
depending on the input current.
The display updates the reading.
For current ≤ 3A use the 3.15A
terminal.
For current up to 12A use the 10A
terminal.
