GW Instek GDM-906 Series User Manual

ADVANCED MEASUREMENT
75
F4 (BeepVol)
key to define
beep volume
Press the F4 (BeepVol) key to show the menu
of Volume level of Beep as the following.
Press the F2 - F4 key to select volume level.
Once the latest hold value is updated, the
beep sounds based on the defined volume.
Press the F1 key to set Beep volume off.
F2 (MathDisp)
key to show
STAT & Math
Press the F2 (MathDisp) key to show the
option menu as the figure below shown.
Proceed to the F2 (STAT) or F3 (Math)
display in accord with the following
chapters.
Show STAT
result
Background
The STAT page in MathDisp allows you to make
statistical calculations for several measurements
including Minimum, Maximum, Average
Peak-Peak, Standard Deviation and Count.
Operation
Press the F2 (STAT) key to show the
statistical data immediately as the figure below.
View Data
-000.9716
mVDC
Indicates the latest hold value
Minimum
Indicates the minimum data value
Maximum
Indicates the maximum data value
Average
Indicates the mean (average) value
Peak-Peak
Indicates the peak to peak data
STDEV
Indicates the standard deviation of the data
Count
Indicates the latest counts of hold
