ADVANCED MEASUREMENT
85
Press the F1 (Setup) key to toggle between the
1ST and the 2ND measurement to be setup for
filter setting.
Note: only when 2ND measurement is
enabled, you are able to toggle options here.
Otherwise, only the 1ST is available for setup.
Press the F2 (Filter) key to turn On or Off filter
function. The Filter indicator appears on the
display.
Press the F3 (FilterType) key to enter the
subsequent menu. Press the F1 or F2 keys to
select desired filter type.
Press the F4 (FilterCount) key to enter the
subsequent menu. Use the Left/Right arrow keys
to move cursor and scroll Knob key or press
Number keys to enter the desired value.
Press the F6 (Enter) key or the Knob key until
click to confirm the filter count settings.
Range: 2 ~100
Select the Filter Window Method by clicking the
F5 (WinMethod) key. The display changes
accordingly as the figure below shown. Press the
F1 or F2 keys to choose desired Filter Window
Method.
