GW Instek GDS-1000B Series Programming Manual

GDS-1000B Programming Manual
144
Example
:TRIGger:BUS:B1:I2C:ADDRess:DIRection READ
Sets the direction to READ.
:TRIGger:BUS:B1:I2C:DATa:SIZe
Description
Sets or queries the data size in bytes for the I
2
C
bus.
Note
This setting only applies when the I
2
C trigger is set
to trigger on Data or Address/Data
Note
This command is only applicable when the Serial
Bus Decode (DS1B-BUS) option is installed. See the
user manual for details.
Syntax
:TRIGger:BUS:B1:I2C:DATa:SIZe {<NR1> | ? }
Related
commands
:TRIGger:BUS:B1:I2C:CONDition
Parameter
<NR1>
Number of data bytes (1 to 5).
Return parameter
<NR1>
Returns the number of bytes.
Example
:TRIGger:BUS:B1:I2C:DATa:SIZe 3
Sets the number of bytes to 3.
:TRIGger:BUS:B1:I2C:DATa:VALue
Description
Sets or queries the triggering data value for the I
2
C
bus when the I
2
C bus is set to trigger on Data or
Address/Data.
Note
This command is only applicable when the Serial
Bus Decode (DS1B-BUS) option is installed. See the
user manual for details.
Syntax
:TRIGger:BUS:B1:I2C:DATa:VALue {<string> | ? }
Related
commands
:TRIGger:BUS:B1:I2C:DATa:SIZe
Set
Query
Set
Query
