GW Instek GDS-1000B Series Programming Manual

GDS-1000B Programming Manual
154
Note
This command is only applicable when the Serial
Bus Decode (DS1B-BUS) option is installed. See the
user manual for details.
Syntax
:TRIGger:BUS:B1:CAN:IDentifier:VALue {<string>|?}
Related
Commands
:TRIGger:BUS:B1:CAN:IDentifier:MODe
Parameter/
Return parameter
<string>
The size of the string depends on the
data size setting. The string must be
enclosed in double quotes, “string”.
String contents:
x = don’t care
1 = binary 1
0 = binary 0
Example
:TRIGger:BUS:B1:CAN:CONDition ID
:TRIGger:BUS:B1:CAN:IDentifier:MODe STANDARD
:TRIGger:BUS:B1:CAN:IDentifier:VALue
"01100X1X01X"
:TRIGger:BUS:B1:CAN:IDentifier:VALue?
>01100X1X01X
:TRIGger:BUS:B1:CAN:IDentifier:DIRection
Description
Sets or queries the address bit as read, write or
don’t care.
Note
This command is only applicable when the Serial
Bus Decode (DS1B-BUS) option is installed. See the
user manual for details.
Syntax
:TRIGger:BUS:B1:CAN:IDentifier:DIRection
{READ|WRITE|NOCARE|?}
Parameter/
Return parameter
READ
Sets read as the data direction
WRITE
Sets write as the data direction
NOCARE
Sets either as the data direction
Set
Query
