GW Instek GPT-9500 Series User Manual

GPT-9500 Series User Manual
100
AC FREQ
Background
A test frequency of 60Hz or 50Hz can be set,
regardless of the input line voltage. The test
frequency setting only applies to ACW test.
1. Use the PREV & NEXT keys or
scroll wheel to move to the AC
FREQ field.
2. Press the ENTER soft-key followed
by using the scroll wheel to select
an option.
AC FREQ
50Hz, 60Hz
3. Press the ENTER soft-key to
confirm the setting
RAMP JUDG.
Background
In theory, neither PASS nor FAIL status is
judged during the ramp up time. However,
RAMP JUDG. enables judgment during the
ramp up duration instead for certain application.
1. Use the PREV & NEXT keys or
scroll wheel to move to the RAMP
JUDG. field.
