GW Instek GPT-9500 Series - Lineup Overview; Main Features

GETTING STARTED
11
Lineup Overview
Model name
ACW
DCW
IR
Scan - Hi
Scan - Lo
GPT-9503




GPT-9513





Main Features
Performance
 ACW: 5kVAC
 DCW: 6kVDC
 IR: 50V~1kV
 8-CH Scanner
Features
 Ramp up time control
 Fall time control
 Safety discharge
 501 test conditions (MANU mode)
 99 steps per group (AUTO mode)
 99 groups for total 500 memory locations
(AUTO mode)
 Over temperature, voltage and current
protection
 View, Edit, Ready, Test, Stop, High Voltage and
Pass, Fail indicators
 Interlock (configurable)
Interface
 RS232/USB interface for programming
 Signal I/O port for pass/fail/test monitoring
and start/stop control
 Interlock terminal for safety operation
