Page #254 background imageLoading...
Page #254 background image
GPT-9500 Series User Manual
254
Example: SAFE:STEP3:IR:RANG:LOW 0.0005
The IR measured current value of step3 is set to 500uA. Thus,
meanwhile the selected IR range lower than the current can be
measured is 500uA.
[:SOURce]:SAFEty:STEP<n>:IR:RANGe:LOWer?
Returns the range for IR in selected step.
Parameter<n>: <NR1>(1 ~ 99)
Return parameter: <NR3>
Example: SAFE:STEP3:IR:RANG:LOW?
> +5.000000E-04
The setting range for IR of step3 is 500uA.
[:SOURce]:SAFEty:STEP<n>:IR:RANGe:AUTO
Sets the auto range status for IR in selected step.
Parameter<n>: <NR1>(1 ~ 99)
Parameter: 0 | 1 | OFF | ON
Example: SAFE:STEP3:IR:RANG:AUTO 1
Sets the auto range for IR of step3 to on.
[:SOURce]:SAFEty:STEP<n>:IR:RANGe:AUTO?
Returns the auto range status for IR in selected step.
Parameter<n>: <NR1>(1 ~ 99)
Return parameter: 0 | 1
Example: SAFE:STEP3:IR:RANG:AUTO?
> 1
The auto range status for IR of step3 is on.
