OPERATION
109
The No. info is superimposed
in AUTO test result display
It is available to press the EXIT soft-key anytime
to leave the AUTOPARA setting page.
Getting the Reference Value
The REF value (REF#) acts as an offset. The REF#
is subtracted from the measured current (ACW,
DCW) or measured resistance (IR). The GET
REF# for AUTO test is particularly convenient in
that it helps obtain, with single click, the REF
value for each MANU step at one time.
1. Press the MANU/AUTO soft-key
to select AUTO option.
2. Press the MORE soft-key followed
by pressing GET REF# soft-key.
The AUTO group page will be shown where it
requests HV output terminal needs to be OPEN
prior to pressing START key to get REF#.
