GPT-9500 Series User Manual
66
Setting the IR Test Range
Background
Due to the measured current range in IR test is
way to broader per varied DUT, it is suggested
to select an appropriate current range for the
applied DUT. This is only available for IR test.
Steps
1. Press the MANU/AUTO soft-key
to select MANU option.
2. Press the EDIT soft-key followed by
clicking the PAGE key for twice.
x 2
3. Press the RANGE soft-key followed
by using the scroll wheel to set the
current range.
RANGE
5μA, 50μA, 500μA, 5mA, AUTO
Set the current RANGE
4. Press the SAVE soft-key to complete.
