GW Instek GPT-9500 Series User Manual

GPT-9500 Series User Manual
44
Setting the Test Voltage
Background
The test voltage can be set from 0.050kV to 5kV
for ACW, 0.050kV to 6kV for DCW and 0.050kV
to 1kV for IR.
Steps
1. Press the MANU/AUTO soft-key
to select MANU option.
2. Press the EDIT soft-key followed
by clicking the VOLTAGE soft-key.
3. Use the scroll wheel to set the test
voltage.
ACW
DCW
IR
0.050kV ~ 5kV
0.050kV ~ 6kV
0.050kV ~ 1kV
Set the test voltage
4. Press the SAVE soft-key to complete.
