Viewing the Parameters Settings
Background
After setting up the parameters of each test
mode (ACW, DCW and IR), user can check
those settings anytime with ease.
Steps
1. Press the MANU/AUTO soft-key
to select MANU option.
2. Use the scroll wheel to go to the
target MANU step.
3. The parameters settings from each
test mode are shown below. Use
the PAGE key to toggle pages.
DCW
DCW parameters – page 1
DCW parameters – page 2
