• Click Settings in the upper-right corner to launch either of the following:
â—‹ Device Manager - Storage Navigator to perform any advanced storage
management operations that are not available in Storage Advisor.
â—‹ Configure storage system encryption using Storage Navigator.
â—‹ If the storage system includes optional NAS modules, you can launch
NAS Manager to perform operations that are not available in Storage
Advisor.
• Review the information gauge regarding available capacity in storage
system.
• Use the Alerts tiles to access alerts related to the storage system.
• Click Review Tiered Categories to open the Tier Management page to view
and edit tier categories.
• View attributes about the storage system, including information that
Storage Advisor discovered about the system, such as model, serial
number, and SVP IP address.
Field
Description
Model Model name of the storage system.
S/N Storage system serial number.
SVP Version SVP firmware version.
HORCM Version 01-33-03/06
A data replication component residing on the server.
Cache Capacity Total cache capacity configured on the storage system.
Unused Disks Disks that are not assigned as hot spares or used to create parity
groups.
Unused Disk Capacity Total unused capacity of all disks.
SVP IP Address Address of the service processor on the storage system.
Maintenance Utility IP
Addresses 1 and 2
Configured automatically when the storage system is onboarded.
Health Status (for a
cluster, if any)
Robust Operating normally, with no failures in
the cluster interconnect, the
management network, or quorum
device communication.
Degraded Operating, but one or more nodes has
failed or there has been a failure in
connectivity.
Status (of nodes, if any) Online The cluster node is a part of the cluster
and is exchanging heartbeats (periodic
signals) with the other cluster
members.
92 Configuring the storage system
System Administrator Guide for VSP Gx00 models and VSP Fx00 models
