COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 157
954 SmartServo FlexLine
Name Explanation Default Value
Function
Part
Function
[QV Link function
instance]
Function Instance of the
linked QV board
<0>
Board Board Specific
[Linked Primary Value] PV / SV value of linked PV
board in the set unit code
<0>
[Linked Secondary
Value]
PV value of linked SV
board in the set unit code
<0>
[Linked Tertiary Value]
PV value of linked TV board
in the set unit code
<0>
[Linked Quarternary
Value]
PV value of linked QV
board in the set unit code
<0>
Name Explanation Default Value
Function
Part
Function
[HART SV unit code]
Unit code for linked SV
<UNIT_CODE_
UNKNOWN>
Function 1 Communica
tion (HART
communica
tion)
[HART TV unit code]
Unit code for linked TV
<UNIT_CODE_
UNK
N
OWN
>
[HART QV unit code]
Unit code for linked QV
<UNIT_CODE_
UNK
N
OWN
>
[Configuration changed
Counter]
Increments every time the
configuration is changed
<0>
[Device ID] Same as Enraf Serial
number. This is a unique
number to every board.
[Device Type]
Device type registered with
the HART Communication
Foundation
<127>
[Manufacturer ID Number]
Manufacturer ID registered
with the HART
Communication Foundation
<148>
[Number of Preambles]
Number of preambles
required for a request from
the HART master
<7>
[Number of Response
Preambles]
Number of preambles in the
HCI-HAO response stream
<7>
[Fixed Current Value] Fixed analog output current
set by HART command 40
<0> Function 2 Sensor
(Analog
Output)
[Loop Current Mode] If HART mode selected is
<Standard 4-20mA>, then it is
enabled.
If HART mode selected is
<Fixed 4-20mA>, then it is
disabled.
<Enabled>
[Percentage of Range] Percentage of current PV
with respect to the limits set
<0>
