COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 215
954 SmartServo FlexLine
Safety Function Status Code User Action Latching
Default
Burnout
Default
PRODUCT LEVEL DATA CORRUPTED
The product level value received from
the tank gauge is corrupted.
Service the
CAN-SERVO
board
Disabled High
PRODUCT LEVEL DATA TOO OLD
The product level value received from
the tank gauge is more than 5 seconds
old.
Service the
CAN-SERVO
board
Disabled High
PRODUCT LEVEL DATA FROM
WRONG SOURCE
The product level value was received
from a source that is not a 954
SmartServo tank gauge.
Remove the
incompatible
board
Disabled High
PRODUCT LEVEL NOT GOOD
The product level value received from
the tank gauge has a bad status.
Service the
CAN-SERVO
board
Disabled High
PRODUCT LEVEL SCAN TIMEOUT
No product level value has been
received for more than 5 seconds.
Service the
CAN-SERVO
board
Disabled High
DISPLACER NOT ON PRODUCT
LEVEL
The Servo tank gauge displacer is not
positioned on the product level.
Deploy displacer
to measure
product level
Disabled High
PRODUCT LEVEL OVERFILL
The product level value is above the
threshold value.
Correct the
product level
Disabled High
PRODUCT LEVEL UNDERFILL
The product level value is below the
threshold value.
Correct the
product level
Disabled High
FIXED FREQUENCY ABOVE
SETPOINT
The Servo tank gauge displacer is at the
high motor limit.
Calibrate the
servo level
measurement
Disabled High
FIXED FREQUENCY BELOW
SETPOINT
The Servo tank gauge displacer is at the
low motor limit.
Calibrate the
servo level
measurement
Disabled High
BOARD TEMPERATURE FAILURE
The temperature of the FII-SIL module
is excessive.
Replace the
CAN-SIL board
Disabled High
