COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 79
954 SmartServo FlexLine
7.3.4.11 Configuration
Name Value Range Default Value Explanation
[Displacer type] <no_displacer_type_selected>
<s0815345_cptfe_110mm>
<s0815344_cptfe_90mm>
<s0815343_cptfe_45mm>
<s0815360_cptfe_25mm>
<s0815350_aisi316_density_90mm>
<s0815355_aisi316_density_45mm>
<s0815316_stabigauge_90mm>
<s0815362_cptfe_spider_90mm>
<other_displacer_type>
<No displacer
type selected>
During
commissioning a
displacer type can be
selected from a list.
[Measuring
range and wire
material]
<no_measuring_range_selected>
<27m_88ft_aisi316>
<27m_88ft_hastelloy_c22>
<27m_88ft_tantalum>
<37m_121ft_aisi316>
<37m_121ft_invar>
<37m_121ft_tungsten>
<47m_154ft_aisi316>
<47m_154ft_tungsten>
<150m_492ft_aisi316>
<other_measuring_range_or
_wire_material>
<No measuring
range
selected>
During
commissioning the
measuring range and
wire material can be
selected from a list.
[Drum
circumference]
<0.0>
The drum
circumference.
[Set point 1] <0.208>
This entity defines
the wire
weight/tension if it
reaches the interface
1 (product level)
transition.
[Set point 2] <0.208>
This entity defines
the wire
weight/tension if it
reaches the interface
2 (2 different product
densities) transition.
[Set point 3] <0.208>
This entity defines
the wire
weight/tension if it
reaches the interface
3 (water level)
transition.
