COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 81
954 SmartServo FlexLine
7.3.4.12 Advanced Configuration
Name Value Range Default Value Explanation
[Displacer area] <0.0065> The displacer area must be
entered at the point where
the displacer touches the
interface when the control
loop is in balance.
[Integration time 1]
[Integration time 2]
[Integration time 3]
<2>
<2>
<2>
Used to filter out (fast)
fluctuations of the resp.
interfaces 1, 2 and 3.
[Wire weight per
unit of length]
<0.00025> This entity is used to
compensate the set point
with the weight of the wire.
[Wire temperature
coefficient]
<1.2E-05> Determines the temperature
expansion coefficient of the
wire (according to a related
table)
[Wire cross
sectional area]
<3.1416E-08> Determines the cross
sectional area of the wire.
[Elasticity
coefficient]
<2E+11> Determines the elasticity
coefficient of the wire
(according to a related table)
Drum blind length <0.0> Determines the non used
part of the wire on the drum
when the wire length > 50m
till 150m. concerning related
calculations.
