COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 83
954 SmartServo FlexLine
Name Value Range Default Value Explanation
[Default density tank
profile stop level]
<0.3>
Determines the tank profile
stop level until where the
density measurements are
performed. The highest is
used, see next entity.
[Density tank profile
stop level]
<-999.9999>
Determines the tank profile
stop level until where the
density measurements are
performed. The highest is
used, see previous entity.
[Density tank profile
method]
<One drum position>
<Multi over drum>
<Multi over drum>
Determines (at a certain level
position) if the density
measurements are done at
only one point at the drum
circumference (unbalance
compensation could help
here) or at multiple points
over the drum circumference
(would filter out drum
unbalance at the same time).
The number of points is
determined by the entity
[Number of tank profile drum
balance points]
[Air density] <1.225>
This air density is used
during density calculations.
Liquid surface
pressure]
<101.3> The pressure at the liquid
surface inside the tank.
Note: For pressurized tanks
this should be the value for
the pressure inside the tank.
[Tank profile] This command starts a tank
profile density measurement.
The density measurement
positions are equally
distributed from the range:
Product level – [Density TP
start distance] until [Density
TP stop level] or [Default
density TP stop level] with
the number of points defined
by [Number of density
measurements (max 50)].
