Honeywell touchpoint Pro User Manual

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
113
8. Maintenance
8.1.4 Cause and Effect Test
Note: Engineer access level is required.
Duringthistest,allelddeviceinputswillbeignoredbytheTouchpointProsystem.TheCauseandEffect
matrix will be evaluated based on simulated input states and outputs will be generated.
Caution: During the Cause and Effect Test, outputs will be generated and relays will be activated. To
avoid any unwanted activation of output devices (e.g. emergency deluge) disconnect them before
starting the test.
This test has two purposes:
1. ToverifythatCauseandEffectmatrixcongurationiscorrectbyforcingthestateoftheinputchannels
to various combinations. The activated/de-activated output channels corresponding to the forced state
of input channels can be viewed on the touchscreen or the Web Server.
2. Tocheckthattheoutputchannelsareconguredcorrectly,includingdelayon/offtimesetc.Byforcing
the state of the output channel to either activate or de-activate the corresponding change in state of
the output device after application of delay on/off times can be viewed on the touchscreen or the
Web Server.
To use the Cause and Effect Test mode:
1. If not already logged in, login with a valid engineer level user name
2. From the System Status screen select the Extras icon then Diagnostics
3. Press the Menu icon
and select Cause and Effect Test
4. Thesystemwillaskyoutoconrm,pressYes to proceed
5. Thesystemwilldisplayaconrmationmessage,clickonOK and you will be automatically navigated
to the Outputs screen
6. Select the channel to be tested and select Output Details from the popup menu
7. Press the Menu icon
and select Force Input States to do a full test of the Cause and Effect matrix
(test 1 described above)
8. The system will display a matrix of all the input channels that are linked to the output channel
being tested
9. Select the input channel states that you wish to simulate, and click on Force. The cells corresponding
to the forced states will be coloured
10. The system will return to the Outputs screen where the results of the forced input states can be viewed
11. When ready, return to the Output Details screen, press the Menu icon
and select Clear Force
12. Repeat steps 6-11 for the next channel
13. To force the output relays (test 2, described above) select the channel to be tested and select
Output Details from the popup menu
