Honeywell touchpoint Pro User Manual

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
148
10. Specications
10.3.1 Floor Standing Cabinets Front Access
Part Number
TPPR-V-1250 TPPR-V-1252 TPPR-V-1254
Material
No Ventilation Natural Ventilation Forced Ventilation
Dimensions (H x W x D)
2075 x 800 x 694 mm
Weight
230 Kg
Operating Conditions
Ventilated: -20 to +55 °C (T
a
), 10 – 90 %RH (non-condensing)
Non-Ventilated: -20 to +55 °C (T
a
), 0 – 100 %RH (condensing)
Power Supplies
100 – 240 VAC, 50/60 Hz, 0 – 25 A max.
24 VDC Nominal (18 – 32 VDC), 0 – 100 A max.
Pmax
See Rating Plate
10.3.2 Floor Standing Cabinets Rear Access
Part Number
TPPR-V-1260 TPPR-V-1262 TPPR-V-1264
Material
No Ventilation Natural Ventilation Forced Ventilation
Dimensions (H x W x D)
2075 x 800 x 694 mm
Weight
230 Kg
Operating Conditions
Ventilated: -20 to +55 °C (T
a
), 10 – 90 %RH (non-condensing)
Non-Ventilated: -20 to +55 °C (T
a
), 0 – 100 %RH (condensing)
Power Supplies
100 – 240 VAC, 50/60 Hz, 0 – 25 A max.
24 VDC Nominal (18 – 32 VDC), 0 – 100 A max.
Pmax
See Rating Plate
10.4 Power Supplies and Fuses
10.4.1 Power Supply Units (OEM Specications)
Type / Model
QS5.241 QS10.241 QS20.241
Power Supply
120 W (5 A) 240 W (10 A) 480 W (20 A)
Input Voltage Range
85 – 276 VAC; 88 – 187 VDC
Input Frequency Range
50 – 60 Hz ± 6%
Input AC current
1.10 A at 120 VAC
0.62 A at 230 VAC
2.22 A at 120 VAC
1.22 A at 230 VAC
4.56 A at 120 VAC
2.48 A at 230 VAC
Output Voltage
DC 24 V (Adjustable 24 – 28 VDC)
DC OK Relay contact
ratings (max.)
60 VDC @ 0.3 A / 30 VDC @ 1 A / 30 VAC @ 0.5 A resistive load
Protection
Short Circuit, Overload (current limiting), No load, Over Voltage, Over Temperature
Dimension
40 mm x 124 mm x 117 mm
(W x H x D)
60 mm x 124 mm x 117 mm
(W x H x D)
82 mm x 124 mm x 117 mm
(W x H x D)
Operating Temperature
–25 °C to +70 °C (–13 °F to +158 °F)
De–rating (60°C to 70°C)
3 W / °C 6 W / °C 12 W / °C
Storage Conditions
–40° to +85° C (–40° F to +185° F), 5 to 95 %RH (non–condensing)
Operating Humidity
5 to 95 %RH (non–condensing)
