Honeywell touchpoint Pro User Manual

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
201
15. Appendix 2 - Congurable
Parameter Reference Guide
15.2 Analogue Input Module mV Bridge
The Analogue Input Module mV Bridge has the option to use the sensor catalogue (basic / extended),
congureacustomchannel,orcopyfromaconguredchannel(basic/extended).
Note: When making changes using Extended options, it is the user’s responsibility to determine whether
other settings have been affected and to make any corresponding changes.
Ifabasiccongurationisselected,onlythersttwoscreensdetailedbelowwillbeused(Commission
ChannelandFieldDeviceSelection).Therestofthecongurationwillbeprogrammedautomatically,either
from the sensor catalogue or from the channel that is being copied.
Note: If a channel is congured from the sensor catalogue, it is possible to edit individual settings afterwards
(see Section “Editing a Congured Channel”).
Note: For catalytic bead type detectors, the Touchpoint Pro controller is necessary to complete the
measuring circuit. Therefore all commissioned mV channels remain in Inhibit state until they are calibrated.
15.2.1 Commission Channel
Access Level: Administrator
Parameter Name Default Setting Value Range Comment
Channel ID Next available 1 to 64 Can only be assigned during first time configuration.
Otherwise de-commission the channel and re-assign
another channel number
Channel Location Tag “Channel <Channel ID>” Maximum 30
Alphanumeric Characters
30 character location tag name. This is the main
channel description used throughout the interface
Channel Custom ID “Channel <Channel ID>” Maximum 20
Alphanumeric Characters
20 character custom ID. This is displayed on the
“Channel Details” screen and in the Configuration
Report
Note: Channel Location Tag and Channel Custom ID only require Engineer level access for editing
15.2.2 Field Device Selection
Access Level: Administrator
Parameter Name Default Setting Value Range Comment
Field Device Name “Generic Field Device” Maximum 30 Alphanumeric
Characters
If the sensor catalogue is used, a list of available field
devices will be displayed for selection.
If copy channel is being used, this value cannot be
changed
Sensor Name “Generic Sensor” Maximum 30 Alphanumeric
Characters
If the sensor catalogue is used, a list of available gases
and ranges will be displayed for selection.
If copy channel is being used, this value cannot be
changed
