MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
152
10. Specications
10.5 Control Module and User Interface
10.5.1 Controller & Remote Unit DC Input Supply
Input Voltage
DC 24 V (nominal)
DC Input Voltage Range
18 – 32 VDC (Supplied from Self Enclosed Low Voltage source only)
10.5.2 Control Module and User Interface
Description
Front panel User Interface Assembly
Supply Voltage
18 – 32 VDC (Supplied from Self Enclosed Low Voltage source only)
Power Consumption
Maximum 13 W
Ring Communication Physical layer
Isolated RS485
Ring Network Cable
Two x 1 mm
2
twisted pair cable
Relay Outputs
Two x System State Relays
Relay Contacts
Min. 12 VDC, 10 mA
Max. 5 A at 250 VAC / 30 VDC (non–inductive)
Interfaces
5.7 inch, 320 x 240 pixels (QVGA), Touch Screen LCD
LED and Button Panel with LEDs for Power, Alarm and Fault indication. Buttons for Accept and Reset
functions
Buzzer for audio indication of Alarm/Faults (Sound Level: 85 dB at 100 mm)
USB 2.0 Device Interface with standard Type B USB connector to interface with PC/Laptop for
configuration. Supports USB memory device up to 32 Gb
Standard SD Card Interface 4 Gb to 32 Gb. Supports 24 mm x 32 mm x 2.1 mm cards
10/100 Mbps Ethernet Interface with standard RJ–45 connector
Two x RS–485 Modbus connections supporting maximum 115.2 kbps
Panel Dimension
483 mm x 222 mm
Retention of Real Time Clock
24 hours unpowered
10.6 I/O Modules
10.6.1 Common Specications
Dimensions
35.0 mm x 99.5 mm x 114.5 mm (W x H x D)
Installation
5, 7, 9 or 10-way Communication / Power Rail
Maximum wire size
2.5 mm
2
IP Rating
IP20
EMC
EN 50270
Power supply
18 – 32 VDC (Supplied from Self Enclosed Low Voltage source only)
DIN rail compatibility
TS–35 / 15
Casing material
Polyamide PA 6.6 V0 (UL94)
Operating Temperature Range
–40 °C to +70 °C
Storage Conditions
–40 °C to +70 °C
Operating Humidity Range
10 to 90 %RH (non–condensing)
Weight
210 g
Environmental Protection Class
Equipment Class III, Installation Cat 2, Pollution Degree 2
