Honeywell touchpoint Pro User Manual

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
230
20. Appendix 7 - Logged events and
where they are displayed
All of the events listed below are captured in the Event History of the system. In addition, some are displayed
on the Active Events, Input/Output Details, or Inputs/Outputs screens as appropriate. Each event is logged
with a timestamp and if applicable the module or channel to which it applies.
Note: ADC – Analogue to Digital Converter
AIM – Analogue Input Module
CCB – Control Centre Board
COB – Communication Board
DIM – Digital Input Module
FW – Firmware
HMI – Human Machine Interface (User Interface)
I/O – Input/Output
UI/LHMI – Local User Interface (Touchscreen)
ROM – Relay Output Module
SW – Software
Event Comment
Where Displayed
Specic
Channel Type
(if applicable)
Input
Details
screen
Output
Details
screen
Active
Events
screen
Inputs /
Outputs
screen
49th Module present System has detected that too many
I/O modules are connected
✔
49th Module removed
Accept Button Password Setting
Modified
The Accept button on the Touchpoint
Pro front panel can optionally be
password protected – the setting
has been changed
Active Fault
✔
Active Fault Cleared
Active Warning
✔
Active Warning Cleared
ADC Error Raised for hardware error in IO
Module channel diagnostics
✔
DIM
ADC Error Cleared DIM
AIM Fault Acknowledged
AIM mA Channel Modified
AIM mV Channel Modified
AIM Warning Acknowledged
Alarm
✔ ✔ ✔
Alarm 1
✔ ✔ ✔
mA, mV
Alarm 1 Acknowledged mA, mV
Alarm 1 Cleared mA, mV
Alarm 2
✔ ✔ ✔
mA, mV
Alarm 2 Acknowledged mA, mV
Alarm 2 Cleared mA, mV
Alarm 3
✔ ✔ ✔
mA, mV
