MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
190
14.6.3 Command Poll Registers
Command Poll
Block
Block Active Channel Type Channel ID Command Type Command Data Result
1 41001 41002 41003 41004 41005 41006
2 41101 41102 41103 41104 41105 41106
3 41201 41202 41203 41204 41205 41206
4 41301 41302 41303 41304 41305 41306
5 41401 41402 41403 41404 41405 41406
6 41501 41502 41503 41504 41505 41506
7 41601 41602 41603 41604 41605 41606
8 41701 41702 41703 41704 41705 41706
9 41801 41802 41803 41804 41805 41806
10 41901 41902 41903 41904 41905 41906
Allowed values for the Result register 41n05 (n = 0 to 9)
Value Meaning
0 Success
1 Command not permitted
2 Inter process communication failure
67 Failure
14.6.4 Command Types Available
Note: Function 06 cannot be used for SIL channels
Command Type Description
23 Alarm Acknowledge
24 Alarm Reset
25 Set Inhibit
26 Clear inhibit
Example: Alarm Acknowledge (Command Type)
Register
Block Active
(41n01)
Channel Type
(41n02)
Channel ID
(41n03)
Command Type
(41n04)
Command Data
(41n05)
Result (41n06)
Value
1 105 2 23 0 (Updated upon request
execution)
14. Appendix 1 - Modbus Option
