Honeywell touchpoint Pro - Wiring Diagram AIM mV with Sensor Connectivity

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
218
16. Appendix 3 - Wiring Diagrams
16.8 AIM mV with Sensor connectivity
AIM mV Module
Notes:
1. For all shielded cables, shield (screen) should be connected to Earth tag bar/bus bar provided in Touchpoint Pro enclosure.
E
Channel 1
S
NS
01
1
2
3
Catalytic Sensor
S
NS
Channel 2
S
NS
01
4
5
6
Catalytic Sensor
S
NS
Channel 3
S
NS
01
7
8
9
Catalytic Sensor
S
NS
Channel 4
S
NS
01
10
11
12
Catalytic Sensor
S
NS
Recommended Cable:
3 Core, Twisted, Mesh Type
Shielded, 1.5mm
2
or 2.5mm
2
