12. Ordering Information
12.1 TPPR-M Input and Output Congurator (I/O Congurator)
Part Number Description
TPPR-M Input and Output Congurator (I/O Congurator)
TPPR-M
10 Way Communication/Power Rail (Select up to maximum 10 I/Os)
Consists of a DIN Rail blank panel, 1 Ring Coupling Module and 10 Backplanes
Input and Output Modules (I/O Module)
X None
A Analogue Input Module mV-Bridge
C Analogue Input Module 4-20mA
H Digital Input Module
N Relay Output Module
Customer Set-up
D Default
S Custom
Optional Terminal Block
X None
T Terminal Blocks
TPPR-M A A A A A A A A A A S X
TPPR-M
9 Way Communication/Power Rail (Select up to maximum 9 I/Os)
R Consists of a DIN Rail blank panel, 2 x Ring Coupling Modules and 9 Backplanes; (with additional Ring Coupling
Module for redundant communications)
Input and Output Modules (I/O Module)
X None
A Analogue Input Module mV-Bridge
C Analogue Input Module 4-20mA
H Digital Input Module
N Relay Output Module
Customer Set-up
D Default
S Custom
Optional Terminal Block
X None
T Terminal Blocks
TPPR-M R A A A A A A A A A S X
