Honeywell touchpoint Pro User Manual

MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
90
6. Commissioning
1. If not already logged in, login with a valid engineer level user name
2. From the System Status screen select the Inputs icon
then select the channel to be calibrated
3. Select Calibration from the popup menu
4. Select Zero Adjust, and when ready press OK and apply clean air to the sensor
5. View the gas reading until it is stable, and then press Accept
6. Conrmthatthegasreadingiszero,andpressSave then OK
7. Select First Span
8. Enter the concentration of the span gas and press Accept
9. When ready press OK and apply gas to the sensor
10. View the gas reading until it is stable, and then press Accept
11.Conrmthatthegasreadingiscorrect,andpressSave then OK
12.Removethespangasfromthesensor,andconrmthatthegasreadinghasreturnedtozero
13. Select Clear Inhibit to remove the inhibit from the channel
6.17 Calibrate mA input channel loops
WARNING
Where the sensor / transmitter has the facility, the mA loop should always be calibrated at the
Touchpoint Pro controller by forcing signal levels at the sensor / transmitter. Any gas calibration
required must be carried out at the eld device according to the manufacturer’s instructions.
The Touchpoint Pro controller calibration should not be used to adjust for deciencies in
the sensor / transmitter gas calibration. Failure to observe this can result in signicant
accuracy errors.
Caution: Ensure that any executive action is inhibited before starting this test
Note: Engineer level access is required
Note: If the sensor is an Oxygen sensor that is not being used with a transmitter that has a force mA
function, the zero gas should be 100% v/v Nitrogen, and the span gas should normally be air at 20.9% v/v
Oxygen. The Touchpoint Pro controller calibration should not be used to correct deciencies in the sensor
calibration; instead carry out a gas calibration at the sensor according to the manufacturer’s instructions.
Note: If you wish to enable a calibration reminder for the channel, please edit this setting before starting
calibration (see Commissioning, Editing a Congured Channel and Congurable Parameter Reference
Guide, Calibration Reminder Settings)
To calibrate the mA loop of an input channel, please follow the procedure below in combination with the
relevant instructions in the sensor manual.
