MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
145
10. Specications
10.1.3 19” 5U Remote Unit Enclosure without User Interface
Part Number
TPPR-V-0612
Material
Mild Steel
Earthing Points
M8 (main grounding) other M6
Dimensions (H x W x D)
483 x 222 x 110 mm
Weight
6 Kg
10.2 Wall Mounted Enclosures
All wall mounted enclosures are Equipment Class 1 (grounded) and Installation Category 2, and have
additional restrictions as shown under each sub- heading below.
WARNING
Protect the User Interface from direct exposure to precipitation and sunlight.
AVERTISSEMENT
Protéger l’interface utilisateur des expositions directes au soleil et de la pluie.
10.2.1 Wall Mount Controller Enclosures with User Interface
These units are IP 66, Type 4 & 12, Class 1 (grounded), and can be installed indoors or outdoors in a
Pollution Degree 3 environment that affords total protection from rain, snow and direct sunlight.
The upper T
a
may be reduced dependent on internal power dissipation. See Rating Plates for details.
Part Number
TPPR-V-1210 TPPR-V-1220 TPPR-V-1230
Material
Mild Steel Mild Steel Mild Steel
Dimensions (H x W x D)
600 x 600 x 300 mm 800 x 600 x 300 mm 1200 x 800 x 300 mm
Weight
37 Kg 46 Kg 81 Kg
Operating Conditions
-20 to +55 °C (T
a
), 0 – 100 %RH (condensing)
Power Supplies
100 – 240 VAC, 50/60 Hz, 0 – 20 A max.
24 VDC Nominal (18 – 32 VDC), 0 – 80 A max.
Pmax
See Rating Plate
