10. Specications
10.2.2 Wall Mount Remote Unit Enclosures without User Interface
These units are IP 66 Type 4 & 12, Class 1 (grounded), and can be installed indoors or outdoors in a
Pollution Degree 4 environment, and can be exposed to rain, snow and direct sunlight.
The upper T
a
may be reduced dependent on internal power dissipation. See Rating Plates for details.
Part Number
TPPR-V-1215 TPPR-V-1225
Material
Mild Steel Mild Steel
Dimensions (H x W x D)
600 x 600 x 300 mm 800 x 600 x 300 mm
Weight
37 Kg 46 Kg
Operating Conditions
-20 to +65 °C (T
a
), 0 – 100 %RH (condensing)
-40 to +65 °C (T
a
) (modules only)
Power Supplies
100 – 240 VAC, 50/60 Hz, 0 – 20 A max.
24 VDC Nominal (18 – 32 VDC), 0 – 80 A max.
Pmax
See Rating Plate
10.2.3 Hazardous Area Remote Unit Enclosure without User Interface
WARNING
Do not open when a ammable gas atmosphere is present.
(Class 1 Div.2, Class 1 Zone 2, and Zone 2 [ATEX])
AVERTISSEMENT
Ne pas ouvrir l’équipement dans des atmosphères contenant des gaz inammables.
(Classe 1 Div.2, Classe 1 Zone 2, et Zone 2 [ATEX])
WARNING: EXPLOSION HAZARD
Substitution of components may impair suitability for Class 1 Div.2, Class 1 Zone 2, and
Zone 2 [ATEX] non-incendive approval.
AVERTISSEMENT: RISQUE D’EXPLOSION
Substituer des composants peut compromettre la conformité de la Classe 1 Div.2, Classe
1 Zone 2, et de la Zone 2 [ATEX] pour l’approbation de produits non inammables.
WARNING
Wiring to and from this enclosure must utilise wiring methods suitable for Class 1
Div.2, Class 1 Zone 2, and Zone 2 [ATEX] Hazardous Locations as appropriate to the
installation.
AVERTISSEMENT
Le câblage de ce boîtier doit respecter les méthodes d’installation appropriées en ce
qui concerne les zones dangereuses de la Classe 1 Div. 2, de la Classe 1 Zone 2 et de la
Zone 2 [ATEX].
