MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
114
8. Maintenance
14. Press the Menu icon and select Force from the popup menu. The output will now be activated and
 theresultcanbeveried
15. When ready, select the channel again, and select Clear Force from the popup menu
16. Repeat steps 13-15 for the next channel
17. When the test is complete, return to the System Status screen and select the Extras icon then
Diagnostics
18. Press the Menu icon
and select Stop Cause and Effect Test
19.Thesystemwillshowaconrmationmessagethatithasreturnedtonormaloperation
WARNING
Ensure that the system is returned to normal operation once testing is complete.
8.2 Routine maintenance
• Visually inspect all cabling
• Check for perishing or loose connections
• Clean the screen of the Touchpoint Pro Controller with a soft cloth and mild detergent
• Check for dust contamination (particularly for rack mount units)
• Periodicallyexercisetherelaystoconrmfunctionality
• Check the condition of the enclosure for corrosion, deterioration of door seals, blocked ventilation seals,
 loosexingsandotherdamagethatcouldimpairthesafetyandoperationoftheequipment.
Caution: Do not use solvent to clean any part of the Touchpoint Pro system
8.3 Exercise the relays
Note: Operator level access is required to Force a channel. Engineer level access is required to Clear Force.
Caution: Disable any operations or actions that may result from relay activation before starting this test
Relay output channels can be tested by forcing the relays to an active state:
1. If not already logged in, login with a valid engineer level user name
2. From the System Status screen select the Inputs icon then the Outputs icon
3. Select the channel to be tested, and select Force from the popup menu
4. When ready, select the channel again, and select Clear Force from the popup menu
5. Repeat steps 3 and 4 for all relay output channels
