MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
24
2. Overview / Introduction
2.8 Sensor Catalogue
Forconvenientsensorconguration,theTouchpointProControllerisloadedwithasensorcatalogue,which
containsacompletelistingofallHoneywellAnalytics’gassensors,eachwithafulldefaultconguration
setting.Ausercanchoosetocongureinputchannelsettingsfromthesensorcatalogue,resultingina
threestepcongurationprocess–selectchannelID,programchanneltagsandselectsensorandgas.The
restofthecongurationwillbeloadedautomatically.Thefullcongurationcanbeviewedafterwards,and
individual parameters changed if desired.
Conguration and Visualisation
(Touchscreen, LEDs, Sounder, Buttons)
Actuators Sensors
Laptop Conguration
(PC Conguration Software)
Removable Memory
Visualisation (Web Server)
Master Relays
Touchpoint Pro
Controller
Gateway
Fig 2.5 Touchpoint Pro Interfaces
