MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
144
10. Specications
This section contains basic information about the various Touchpoint Pro major equipment and assemblies.
Note: Power Supply Fluctuations are not to exceed ±10 % of nominal.
Note: All equipment in this manual is rated to +2000 m (6562 ft) altitude maximum.
10.1 Rack Mounted Equipment
All rack-mounted enclosures are Equipment Class 1 (grounded) and Installation Category 2.
WARNING
This apparatus must be installed in a suitable enclosure which provides a Pollution
Degree 2 environment in ordinary (safe area) locations.
AVERTISSEMENT
Cet appareil doit être installé en zone sure dans un boitier conforme au niveau 2 de
pollution environnementale.
Rack mounted equipment (with or without a User Interface) shall only be installed in ordinary (safe area)
locations that provide a Pollution Degree 2 environment.
In addition the enclosure shall provide a level of protection of at least IP20 / Type 1 / Class 1 (grounded) to
mitigate the risk of electrical shock.
Power Supply ratings and ambient operating conditions for rack mounted installations are dependent on the
type and density of components that are installed. Also the upper Ta may be reduced dependent on internal
power dissipation. See individual component Rating labels for further details.
10.1.1 Touchpoint Pro User Interface only
Part Number
TPPR-V-0852
Material
Mild Steel w. Membrane panel
Earthing Points
M8 (main grounding) other M6
Dimensions (H x W x D)
225 x 360 x 70 mm
Weight
4 Kg
10.1.2 19” 5U Rack Enclosure with User Interface
Part Number
TPPR-V-0602
Material
Mild Steel
Earthing Points
M8 (main grounding) other M6
Dimensions (H x W x D)
483 x 222 x 110 mm
Weight
12 Kg
