MAN0923_Issue 3_04/15 Touchpoint Pro
Operating Instructions
159
12. Ordering Information
TPPR-M
9 Way Communication/Power Rail (Select up to maximum 9 I/Os)
H Consists of a DIN Rail blank panel, 1 x Ring Coupling Module, 1 x DIM, and 9 Backplanes; (with additional DIM
for remote PSU failure monitoring)
Input and Output Modules (I/O Module)
X None
A Analogue Input Module mV-Bridge
C Analogue Input Module 4-20mA
H Digital Input Module
N Relay Output Module
Customer Set-up
D Default
S Custom
Optional Terminal Block
X None
T Terminal Blocks
TPPR-M H A A A A A A A A A S X
TPPR-M
8 Way Communication/Power Rail (Select up to maximum 8 I/Os)
R H Consists of a DIN Rail blank panel, 2 x Ring Coupling Modules, 1x DIM, and 8 Backplanes;
(with additional Ring Coupling Module for redundant communications and additional DIM for remote
PSU failure monitoring)
Input and Output Modules (I/O Module)
X None
A Analogue Input Module mV-Bridge
C Analogue Input Module 4-20mA
H Digital Input Module
N Relay Output Module
Customer Set-up
D Default
S Custom
Optional Terminal Block
X None
T Terminal Blocks
TPPR-M R H A A A A A A A A S X
