20. Appendix 7 - Logged events and
where they are displayed
Event Comment
Displayed
Specic
Channel Type
(if applicable)
Input
Details
screen
Output
Details
screen
Active
Events
screen
Inputs /
Outputs
screen
Alarm 3 Acknowledged mA, mV
Alarm 3 Cleared mA, mV
Alarm acknowledged
Alarm cleared
Auxiliary output overload Occurs when a short circuit is
detected on one of the ROM
auxiliary voltage output channels
✔ ✔
ROM
Auxiliary output overload
acknowledged
ROM
Auxiliary output overload cleared ROM
Bead Current Fault When bead current for channel
deviates +/-1% from configured
value.
✔
mV
Bead Current Fault Cleared mV
Buzzer Activation Settings
Modified
The buzzer can be configured to
determine by which event types it
is activated – the setting has been
changed
Calibration Active
Calibration Inactive
Calibration Overdue The configured ‘Calibration
Reminder Interval’ has been
exceeded
mA, mV
Calibration Overdue Cleared mA, mV
Cause and Effect Test ended
Cause and Effect Test started
✔
CCB Configuration Modified
CCB FW Update Logged when CCB firmware is
updated
CCB Master Configuration
transferred
CCB configuration has been
transferred from the master to the
redundant CCB
CCB Redundancy Mode changed CCB redundancy mode can be
either single or dual CCB
CCB Redundant Configuration
transferred
CCB configuration has been
transferred from the redundant to
the master CCB
CCB-COB Communication lost Error in the system, or fault with
CCBs
Channel Decommissioned All
