5-134
Hardkey and Softkey Reference
Recall
Delete Seq[n] Reg[nn]
Press this softkey to delete the contents of a specified register in a specified
sequence. Do not press this softkey until you have selected the correct sequence
and register using the
Select Seq and Recall Reg softkeys. For example, if you
want to delete the contents of register 5 in sequence 4, press
Select Seq. The
currently selected sequence is displayed in the active entry area. Change the
number to 4 using the up and down arrow keys, the front panel knob, or enter a 4
using the numeric keypad and press the
Enter terminator softkey. Sequence 4 is
now displayed in all softkeys which specify a sequence in this menu. Now select
register 5. (Remember, you must first have saved an instrument state to this
register in sequence 4.) Press
Recall Reg. The recall register number becomes the
active function. Enter the number 5 using the numeric keypad and press the
Enter
terminator softkey. The instrument state is restored from this register and register
5 is now displayed in all softkeys which specify a register number in this menu.
Now press
Delete Seq [4] Reg[05] and register 5, stored in sequence 4, will be
deleted. The instrument state that you had recalled from this register remains,
however, until you change it. If you deleted this register in error, you can
immediately resave it using the
Save Seq[n] Reg[n] softkey in the Save menu.
NOTE: This softkey has exactly the same function as the softkey with the identical name in the front
panel Save key menu.
Softkey Location: Press Recall, Delete Seq[n] Reg[nn]
Recall Reg
Press this softkey to recall an instrument state from a saved register. Recalling a
register also selects that register number for all softkeys which specify a register
number in this menu. For example, if you want to select register 5, press
Recall Reg. (Remember, you must first have saved an instrument state to this
register in the current sequence identified by the
Select Seq softkey. If there is
nothing saved, you cannot recall it.) The recall register number becomes the active
function. Enter the number 5 using the numeric keypad and press the
Enter
terminator softkey. The instrument state is restored from this register and register
5 is now displayed in all softkeys which specify a register in this menu. You can
also use the front panel knob and the up and down arrow keys to scroll through all
saved registers for the selected sequence, recalling each instrument state.
Softkey Location: Press
Recall, Recall Reg
IEEE 488.2 Common Commands:
*RCL <reg>[, <seq>]
