HP ESG Series User Manual

5-156
Hardkey and Softkey Reference
Sweep/List
Immediate
This softkey is one of the choices in both the Sweep Trigger menu and the Point
Trigger menu. Press either the
Sweep Trigger softkey or the Point Trigger softkey
to view these menus. Choosing
Immediate in the Sweep Trigger menu
immediately triggers the current sweep when you press the
Single Sweep softkey.
When sweep repeat is continuous and
Immediate is chosen for the sweep trigger,
then sweeps are triggered consecutively (a new sweep is triggered as soon as the
current sweep ends). Choosing
Immediate in the Point Trigger menu causes the
sweep to pause for the dwell time at each point after the hardware has been set up
for that point’s frequency and amplitude.
Softkey Location: Press
Sweep/List, More (1 of 2), Sweep Trigger, Immediate
or press Sweep/List, More (1 of 2), Point Trigger, Immediate
Status after Normal Preset: Sweep and point trigger are set to Immediate
SCPI Commands:
[:SOURce]:LIST:TRIGger:SOURce IMMediate
[:SOURce]:LIST:TRIGger:SOURce?
Insert Item
Press this softkey to place a copy of the selected item directly below that item in
the sweep list. First use the up and down arrow keys until the item you wish to
copy is selected. Press
Insert Item and an identical copy of the selected item is
placed below it.
Softkey Location: Press
Sweep/List, Configure List Sweep, Insert Item
Insert Row
Press this softkey to place a copy of the selected row directly below that row in the
sweep list. First use the up and down arrow keys until any item is selected in the
row you wish to copy. Press
Insert Row and an identical copy of the selected row
is placed below it.
Softkey Location: Press
Sweep/List, Configure List Sweep, Insert Row
