HP ESG Series User Manual

9-4
Specifications
HP ESG Series Signal Generators Specifications
Internal Reference Oscillator
Output
Stability:
Standard
(typical)
High Stability
(Option 1E5)
Aging Rate < ±2 ppm/year < ±0.1 ppm/year or
< ±0.0005 ppm/day after
45 days
Temperature
(0 to 55°C)
< ±1 ppm < ±0.05 ppm, typical
Line Voltage < ±0.1 ppm
(+5%, −10%)
< ±0.002 ppm, typical
(+5%, −10%)
Timebase Reference Output:
Frequency: 10 MHz
Amplitude: > 0.35 V
rms
into 50Ω load
External Reference Input:
Frequency: 1, 2, 5, 10 MHz ± typically 10 ppm (typically 1 ppm, Opt. 1E5)
Amplitude: > 0.15 V
rms
Input Impedance: 50Ω
Range:
250 kHz to 1000 MHz: +13 to −136 dBm
> 1000 MHz to 3000 MHz: +10 to −136 dBm
> 3000 MHz to 4000 MHz: +7 to −136 dBm
