INS
GUI User’s Manual
Inertial Labs, Inc
TM
Address: 39959 Catoctin Ridge Street, Paeonian Springs, VA 20129 U.S.A.
Tel: +1 (703) 880-4222, Fax: +1 (703) 935-8377 Website: www.inertiallabs.com
100
Step 12. To stop readout and data displaying click “Stop” button. If
the data were written in a file then the writing stops too.
Default directory for saved files is “data” subdirectory placed in the directory
where file INS_GUI_*.exe is located. Default name of file with saved data is
generated automatically and consists of the INS serial number, date and
time digits separated by dash symbols where the first 4 digits are the year,
the next 2 digits are the month, then 2 digits of day, next digits are hours,
minutes and seconds of operation start. At the saving data, two files of the
same name with .bin and .prm extensions are saved in the specified folder.
In .bin files the measured data is saved, and in .prm files the INS
microprocessor parameters, at which this data was obtained, are saved. For
example, A1240013-2012-11-20-12-14-26.bin corresponds to data saved
from the INS s/n A1240013 on 2012, November 20
th
, 2012, at 12:14:26.
Note. You can preset name of file for data writing. For this select item “Save as” in the
“File” menu and enter desirable file name.
Step 13. Repeat Step 9 – Step 12 as many times as you need.
Step 14. To close standard operation mode window (Fig. 5.1 – Fig.
5.5) click the icon in the title of current tab.
Step 15. Select “Stop INS” (Fig. 3.3) from the “Run” menu, or click
button.
To get the saved data as text file, do the following:
Step 16. Select “Report of experiment” from the “Convert“ menu
(Fig. 3.6) or press F8 in the main menu or click button (Fig. 3.1). A
standard Windows “Open” window will open.
Step 17. Select the necessary file with extension .bin. Click “ОК”. A .txt
file will be created with the same name and in the same folder as the
selected .bin file, with format set in Step 6.
Note. When large file data is processed then some time is necessary for text file saving.
If you will start new operations with GUI software before end of text file saving, then GUI
software will appear as not responding or locked. Just wait some time for saving end,
after that GUI software will be unlocked.
