8 - 54
HAPSITE ER Operating Manual
7 To return to the previous view, right click on the chromatogram and click Chro
Subtract from the menu to deselect. (See Figure 8-113.)
Figure 8-113 Deselecting Chromatogram Subtract
8.11 Right-Click Menus Within Data Review
8.11.1 Right-Clicking in the TIC Window
Figure 8-114 shows the functions available when right-clicking on the TIC window.
Figure 8-114 Right Clicking in the TIC Window
Common Scale . . . . . . . . . . . . . . . . When checked, all RIC plots will be plotted to
the same scale; when not checked all RIC
plots will be individually scaled to 100%.
Select Scan . . . . . . . . . . . . . . . . . . . Allows the scan cursor to select a specific
scan in order to view the desired mass
spectrum.
View All Data . . . . . . . . . . . . . . . . . . Rescales the plot to display the entire run.
Also accessed by F-11.
View Temperature Profile. . . . . . . . Plots the GC temperature profile of the
method.
