The functions of the buttons change to adapt to different operations and are
displayed on the left of the screen. Press Next Menu to display alternate Main
screen menus (see Figure 3-3).
Figure 3-3 Alternate Main screen menus
Main Menu 3 provides access to functions that can redefine a process and is
available only when the process is stopped.
Spend some time now moving between the three menus. Pay particular attention
to the effects that the Main Menu 2 selections have on the display.
Main Menu 1
Main Menu 2
Main Menu 3
Next
Layer
Start
Zero
Auto /
Manual
Next
Menu
Quick
Edit
Start
Next
Layer
Sensor
Info
Next
Display
Next
Graph
Next
Menu
Start
System
Menu
Film
Menu
Process
Menu
Next
Menu
Zero the thickness
reading on all
channels.
Switch between PID
and Manual power
control.
ccess the most
commonly edited
settings.
Select the next layer
in the process.
Start or Stop the
selected layer.
Switch graph between
rate, deviation, and
power.
Switch the readout
below the graph.
Display detailed
sensor information.
Select the next layer
in the process.
Start or Abort the
process.
Start the selected
layer.
Modify instrument
related settings.
Create or edit films to
be used as layers.
Create or edit process
layers.
Third menu available only
when process is stopped.
Main Menu 1
Main Menu 2
Main Menu 3
