Chapter 5: Console Operation
Output Channels: Internal “Floating” DSP Paths
Eclipse User Guide 2.0 175/ 526
Internal “Floating” DSP Paths
Eclipse provides 16 internal DSP paths which can be assigned
to any output channel (mix bus).
You should use the internal DSP when you want to process the
mix bus rather than individual outputs. For example, if you wish
to EQ every destination fed from the Master, then it makes
sense to EQ the Master bus, and not the separate outputs from
the UM8 card.
There are 16 mono internal processing paths which you can
insert into any output channel (Aux, Group, Matrix or Master)
either pre or post fader. Note that, if you wish, you can insert
two paths: one pre and one post fader in order to increase the
mix bus DSP.
Each internal processing path provides:
• Digital Trim level (from -16dB to +16 dB)
• Phase reverse
• 4-band Parametric EQ
• Compressor
• Gate/Expander
• Low Cut Filter
